What are Heat Recovery Steam Generators?

Heat Recovery Steam Generators, or HRSGs, are boilers that capture and recovers the exhaust of a prime mover such as a combustion turbine, natural gas or diesel engine to create steam.

Stated another way, HRSGs are used to recover energy from the hot exhaust gases in power generation. It is a bank of tubes that is mounted in the exhaust stack. Exhaust gases as much as 800 °F to 1200 °F heat these tubes. Water is pumped and circulated through the tubes and can be held under high pressure to temperatures of 370°F or higher which can be boiled to produce steam.

Furthermore, the HRSG separates the caustic compounds in the flue gases from the occupants and equipment that use the waste heat. HRSG's are found in may combined cycle power plants.

What is a
Heat Recovery Boiler?

A heat recovery boiler make it possible to produce steam, hot water or hot thermal oil from the combustion gas or exhaust stacks from diesel engines, gas turbines (cogeneration), industrial boilers, industrial furnaces or incinerators.

What is a "Waste Heat Boiler"?

A
waste heat boiler is a special type of boiler that generates steam by removing the heat from a process that would have otherwise been wasted.

Waste heat boilers are therefore able to provide significant reductions in fuel and energy expenses, as well as reduce greenhouse gas emissions.

What is a "
Waste Heat Recovery Boiler"?

A
waste heat recovery boiler is, essentially, a boiler without any energy input. Waste heat recovery boilers are usually placed on top of a heat source or stack. Inside the waste heat recovery boiler is a series of tubes that has water inside, that is continuously circulated. The "wasted heat" is recovered on the hot side, and transferred to the water inside the tubes of the waste heat recovery boiler, and then steam is generated to power a steam turbine generator, which then generates power.

For more information on waste heat recovery, please see: www.WasteHeatRecovery.com
